Product Description
Model |
SUN-3.6K-SG04LP1-EU |
SUN-5K-SG04LP1-EU |
SUN-6K-SG04LP1-EU |
Battery Input Data | |||
Battery Type |
Lead-acid or Lithium-ion |
||
Battery Voltage Range (V) |
40~60V |
||
Max. Charging Current (A) |
90A |
120A |
135A |
Max. Discharging Current (A) |
90A |
120A |
135A |
Charging Curve |
3 Stages / Equalization |
||
External Temperature Sensor |
Optional |
||
Charging Strategy for Li-Ion Battery |
Self-adaption to BMS |
||
PV String Input Data | |||
Max. DC Input Power (W) |
4680W |
6500W |
7800 |
PV Input Voltage (V) |
370V (125V~500V) |
||
MPPT Range (V) |
150~425V |
||
Full Load DC Voltage Range |
300~425V |
||
Start-up Voltage (V) |
125V |
||
PV Input Current (A) |
11A+11A |
||
No.of MPPT Trackers |
2 |
||
No.of Strings Per MPPT Tracke |
1+1 |
||
AC Output Data | |||
Rated AC Output and UPS Power (W) |
3600W |
5000W |
6000W |
Max. AC Output Power (W) |
3960W |
5500W |
6600W |
Peak Power (off grid) |
2 times of rated power, 10 S |
||
AC Output Rated Current (A) |
15.7A |
21.7A |
27.3 |
Max. AC Current (A) |
16.4A |
22.7A |
30A |
Max. Continuous AC Passthrough (A) |
35A |
||
Power Factor |
0.8 leading to 0.8 lagging |
||
Output Frequency and Voltage |
50/60Hz; 220/230 / 240Vac (single phase) |
||
Grid Type |
Single Phase |
||
Current Harmonic Distortion |
THD<3%>
|
||
Efficiency | |||
Max. Efficiency |
97.60% |
||
Euro Efficiency |
96.50% |
||
MPPT Efficiency |
99.90% |
||
Protection | |||
PV Input Lightning Protection |
Integrated |
||
Anti-islanding Protection |
Integrated |
||
PV String Input Reverse Polarity Protection |
Integrated |
||
Insulation Resistor Detection |
Integrated |
||
Residual Current Monitoring Unit |
Integrated |
||
Output Over Current Protection |
Integrated |
||
Output Shorted Protection |
Integrated |
||
Output Over Voltage Protection |
Integrated |
||
Surge protection |
DC Type II / AC Type II |
||
Certifications and Standards | |||
Grid Regulation |
VDE 0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116, IEC61727, RD1699: 2011, XP C15-712-3, CEI 0-21 |
||
Safety Regulation |
IEC62109-1, IEC62109-2 |
||
EMC |
EN61000-6-1, EN61000-6-3 |
||
General Data | |||
Operating Temperature Range (℃) |
-25~60℃, >45℃ Derating |
||
Cooling |
Smart cooling |
||
Noise (dB) |
<30db<>
|
||
Communication with BMS |
RS485; CAN |
||
Weight (kg) |
14 |
||
Size (mm) |
330W×580H×232D |
||
Protection Degree |
IP65 |
||
Installation Style |
Wall-mounted |
||
Warranty |
5 years |
||
