Deye SUN-16K-SG01LP1-EU 8KW Hybrid Solar Inverter Three Phase AC 230VAC 60Hz Home VDE Certified Grid Standard Single Phase

Deye SUN-16K-SG01LP1-EU 8KW Hybrid Solar Inverter Three Phase AC 230VAC 60Hz Home VDE Certified Grid Standard Single Phase

Inquiry Contact Us

Description

Is there a problem?
Please contact us to serve you!

+86-13915262017

[email protected]

Inquiry

Description

Product Description

Deye Single Phase Hybrid Inverter

SUN-16K-SG01LP1-EU | 16KW | Single Phase

Deye SUN-16K-SG01LP1-EU 8KW Hybrid Solar Inverter Three Phase AC 230VAC 60Hz Home VDE Certified Grid Standard Single Phase supplier

Specifications

Model	SUN-12K-SG01LP1-EU	SUN-14K-SG01LP1-EU	SUN-16K-SG01LP1-EU
Battery Input Data
Battery Type	Lead-acid or Li-lon
Battery Voltage Range (V)	40~60V
Max. Charging Current (A)	220A	250A	290A
Max. Discharging Current (A)	220A	250A	290A
Charging Curve	3 Stages / Equalization
External Temperature Sensor	Optional
Charging Strategy for Li-Ion Battery	Self-adaption to BMS
PV String Input Data
Max. DC Input Power (W)	15600	18200	20800
Rated PV Input Voltage (V)	500
MPPT Range (V)	150-425
Start-up Voltage (V)	150
PV Input Current (A)	370
No.of MPPT Trackers	2	3
No.of Strings Per MPPT Tracker	2/2	3/2
AC Output Data
Rated AC Output and UPS Power (W)	12000	14000	16000
Peak Power (off grid)	2 times of rated power, 5S
AC Output Rated Current (A)	52.2	60.9	69.6
Max. Continuous AC Passthrough (A)	100
Output Frequency and Voltage	50/60Hz; L/N/PE 220/230Vac (single phase)
Grid Type	Current Harmonic Distortion
Current Harmonic Distortion	THD<3% (Linear load<1.5%)
Efficiency
Max. Efficiency	97.60%
Euro Efficiency	97.00%
MPPT Efficiency	99.90%
Protection	PV Input Lightning Protection, Anti-islanding Protection, PV String Input Reverse Polarity Protection, Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection, Output Shorted Protection, Output Over Voltage Protection
Surge protection	DC Type II / AC Type II
Certififications and Standards
Grid Regulation	IEC61727, IEC62116, IEC60068, IEC61683, NRS 097-2-1
Safety EMC / Standard	IEC62109-1/-2, IEC61000-6-1, IEC61000-6-3, IEC61000-3-11, IEC61000-3-12
General Data
Operating Temperature Range (℃ )	-45~60℃, >45℃ derating
Cooling	Smart cooling
Noise (dB)	<30 dB
Communication with BMS	RS485; CAN
Weight (kg)	48.4
Size (mm)	464W×798.4H×300D
Protection Degree	IP65
Installation Style	Wall-mounted
Warranty	5 years

System Architechture

Deye SUN-16K-SG01LP1-EU 8KW Hybrid Solar Inverter Three Phase AC 230VAC 60Hz Home VDE Certified Grid Standard Single Phase manufacture

The following illustration shows basic application of this inverter. It also includes following devices to have a Complete running system.

- Generator or Utility

- PV modules

Consult with your system integrator for other possible system architectures depending on your requirements.
This inverter can power all kinds of appliances in home or office environment, including motor type appliances such as
refrigerator and air conditioner.

① DC Breaker for battery ② AC Breaker for grid and backup load
SUN 8K-SG: 250A DC breaker SUN 8K-SG: 80A AC breaker

SUN 10K-SG:300A DC breaker SUN 10K-SG:80A AC breaker
SUN 12K-SG:300A DC breaker SUN 12K-SG:80A AC breaker

③ AC Breaker for grid and backup load ④ AC Breaker for home load
SUN 8K-SG: 20A AC breaker Depends on household loads

SUN 10K-SG:32A AC breaker
SUN 12K-SG:32A AC breaker

Our factory

Ningbo Deye Inverter Technology Co., Ltd is dedicated to providing complete photovoltaic power system solutions, including residential and commercial power plants solutions. Also, Deye offers the right device for each application: for all module types, for grid-connection and stand-alone grids as well hybrid inverter system, for small house systems and commercial systems in the Megawatt range. Among them, PV grid-connected inverter power range from 1.5-110kW, Hybrid inverter 3kW-12kW, and microinverter 300W-2000W.

Certificate

Projects cases

Deye SUN-16K-SG01LP1-EU 8KW Hybrid Solar Inverter Three Phase AC 230VAC 60Hz Home VDE Certified Grid Standard Single Phase details

Product packaging

Deye SUN-16K-SG01LP1-EU 8KW Hybrid Solar Inverter Three Phase AC 230VAC 60Hz Home VDE Certified Grid Standard Single Phase factory

FAQ

1. Who are we? We are a professional manufacturer on Solar Panel with many years experience. Our factory and business office located in Wuxi City, Jiangsu Province. 2. What can we provide? We can provide solar panel,solar inverter,solar energy system. 3. Why choose us? A.Higher power generation B.Competitive price C.High quality standard D.Customized service 4. What services can we provide? Accepted Delivery Terms: FOB,CIF,EXW,FAS,CIP,FCA,DDP,DDU； Accepted Payment Currency:USD,EUR,CNY; Accepted Payment Type: T/T,L/C,PayPal,Western Union,Cash.
