Product Description
Model |
SUN-5K-SG01LP1-US |
SUN-6K-SG01LP1-US |
SUN-8K-SG01LP1-US |
Battery Input Data | |||
Battery Type |
Lead-acid or Lithium-ion |
||
Battery Voltage Range (V) |
40~60V |
||
Max. Charging/Discharging Current (A) |
120A/120A |
135A/135A |
190A/190A |
Charging Strategy for Li-Ion Battery |
Self-adaption to BMS |
||
PV String Input Data | |||
Max. DC Input Power (W) |
6500W |
7800W |
10400 |
PV Input Voltage (V) |
370V (125V~500V) |
||
Start-up Voltage (V) |
125V |
||
PV Input Current (A) |
13A+13A |
26A+13A |
26A+26A |
No.of MPPT Trackers |
2 |
||
No.of Strings Per MPPT Tracke |
1+1 |
2+1 |
2+2 |
AC Output Data | |||
Rated AC Output and UPS Power (W) |
5000W |
6000W |
8000W |
Max. AC Output Power (W) |
5500W |
6600W |
8800W |
Peak Power (off grid) |
2 times of rated power, 10 S |
||
AC Output Rated Current (A) |
20.8A |
25.0A |
27.3 |
Max. AC Current (A) |
22.9A |
27.5A |
33.3A |
Output Frequency and Voltage |
50/60Hz; 120/240,208 0.88Un-1.1Un |
||
Grid Connection Form |
2L+N+PE |
||
Certifications and Standards | |||
Grid Regulation |
EN 50549, UNE 217002, NRS 097, IEEE 1547.1, SRD V2.0 |
||
Safety / EMC Standard |
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2, UL 1741 |
||
General Data | |||
Operating Temperature Range (℃) |
-40 to +60℃, >45℃ Derating |
||
Noise (dB) |
<30db<>
|
||
Communication with BMS |
RS485; CAN |
||
Weight (kg)/Size (mm) |
32kg / 420×670×233mm (Excluding Connectors and Brackets) |
||
Protection Degree |
IP65 |
||
Warranty |
5 Years/10 Years |
||
