Specifications
Model |
SUN-8K-SG01LP1 |
SUN-16K-SG01LP1-EU |
Battery Input Data | ||
Battery Type |
Lead-acid or Li-lon |
|
Battery Voltage Range (V) |
40~60V |
|
Max. Charging Current (A) |
220A |
290A |
Max. Discharging Current (A) |
220A |
290A |
Charging Curve |
3 Stages / Equalization |
|
External Temperature Sensor |
Optional |
|
Charging Strategy for Li-Ion Battery |
Self-adaption to BMS |
|
PV String Input Data | ||
Max. DC Input Power (W) |
10400W |
20800 |
Rated PV Input Voltage (V) |
370V (100V~500V) |
|
MPPT Range (V) |
150-425 |
|
Start-up Voltage (V) |
150 |
|
PV Input Current (A) |
370 |
|
No. of MPPT Trackers |
2 |
|
No. of Strings Per MPPT Tracker |
2/2 |
|
AC Output Data | ||
Rated AC Output and UPS Power (W) |
12000 |
16000 |
Peak Power (off grid) |
2 times of rated power, 5S |
|
AC Output Rated Current (A) |
52.2 |
69.6 |
Max. Continuous AC Pass-through (A) |
50 |
100 |
Output Frequency and Voltage |
50/60Hz; L/N/PE 220/230Vac (single phase) |
|
Grid Type |
Current Harmonic Distortion |
|
Current Harmonic Distortion |
THD<3%>
|
|
Efficiency | ||
Max. Efficiency |
97.60% |
|
Euro Efficiency |
97.00% |
|
MPPT Efficiency |
99.90% |
|
Protection |
PV Input Lightning Protection, Anti-islanding Protection, PV String Input Reverse Polarity Protection, Insulation Resistor
Detection, Residual Current Monitoring Unit, Output Over Current Protection, Output Shorted Protection, Output Over Voltage
Protection
|
|
Surge protection |
DC Type II / AC Type II |
|
Certifications and Standards | ||
Grid Regulation |
IEC61727, IEC62116, IEC60068, IEC61683, NRS 097-2-1 |
|
Safety EMC / Standard |
IEC62109-1/-2, IEC61000-6-1, IEC61000-6-3, IEC61000-3-11, IEC61000-3-12 |
|
General Data | ||
Operating Temperature Range (℃ ) |
-25~60℃, >45℃ Derating |
-45~60℃, >45℃ derating |
Cooling | ||
Noise (dB) |
<30 db="">
|
|
Communication with BMS |
RS485; CAN |
|
Weight (kg) |
32 |
48.4 |
Size (mm) |
670×420×233mm |
464W×798.4H×300D |
Protection Degree |
IP65 |
|
Installation Style |
Wall-mounted |
|
Warranty |
5 years |
|
