Product Description
Model |
SUN-5K-SG01LP1 |
SUN-6K-SG01LP1 |
SUN-7.6K-SG01LP1 |
SUN-8K-SG01LP1 |
Battery Input Data | ||||
Battery Type |
Lead-acid or Lithium-ion |
|||
Battery Voltage Range (V) |
40~60V |
|||
Max. Charging Current (A) |
120A |
135A |
190A |
|
Max. Discharging Current (A) |
120A |
135A |
190A |
|
Charging Curve |
3 Stages / Equalization |
|||
External Temperature Sensor |
Optional |
|||
Charging Strategy for Li-Ion Battery |
Self-adaption to BMS |
|||
PV String Input Data | ||||
Max. DC Input Power (W) |
6500W |
7800W |
9880W |
10400W |
PV Input Voltage (V) |
370V (100V~500V) |
|||
MPPT Range (V) |
125V-425V |
|||
Start-up Voltage (V) |
150V |
|||
PV Input Current (A) |
13A+13A |
26A+13A |
26A+26A |
|
No.of MPPT Trackers |
2 |
|||
No.of Strings Per MPPT Tracker |
1+1 |
2+1 |
2+2 |
|
AC Output Data | ||||
Rated AC Output and UPS Power (W) |
5000W |
6000W |
7600W |
8000W |
Max. AC Output Power (W) |
5500W |
6600W |
8360W |
8800W |
Peak Power (off grid) |
2 times of rated power, 10 S |
|||
AC Output Rated Current (A) |
20.8A |
25A |
31.7A / 33A |
33.4A / 35A |
Max. AC Current (A) |
22.9A |
27.5A |
34.9A / 36.3A |
36.7A / 38.5A |
Max. Continuous AC Passthrough (A) |
35A |
40A |
50A |
|
Output Frequency and Voltage |
50 / 60Hz;230Vac (single phase) |
|||
Grid Type |
Single Phase |
|||
Current Harmonic Distortion |
THD<3%(linear load="">
|
|||
Efficiency | ||||
Max. Efficiency |
97.60% |
|||
Euro Efficiency |
97.00% |
|||
MPPT Efficiency |
99.90% |
|||
Protection | ||||
Integrated |
PV Input Lightning Protection, Anti-islanding Protection, PV String Input Reverse Polarity Protection, Insulation Resistor
Detection, Residual Current Monitoring Unit, Output Over Current Protection, Output Shorted Protection, Surge protection
|
|||
Output Over Voltage Protection |
DC Type II / AC Type II |
|||
Certifications and Standards | ||||
Grid Regulation |
VDE 0126,AS4777,NRS2017,G98,G99,IEC61683,IEC62116,IEC61727 |
|||
Safety Regulation |
IEC62109-1, IEC62109-2 |
|||
EMC |
EN61000-6-1, EN61000-6-3 |
|||
General Data | ||||
Operating Temperature Range (℃) |
-25~60℃, >45℃ Derating |
|||
Cooling |
Fan |
|||
Noise (dB) |
<30<>
|
|||
Communication with BMS |
RS485; CAN |
|||
Weight (kg) |
32 |
|||
Size (mm) |
670×420×233mm |
|||
Protection Degree |
IP65 |
|||
Installation Style |
Wall-mounted |
|||
Warranty |
5 years |
|||
1. Who are we?
We are a professional manufacturer on Solar Panel with many years experience. Our factory and business office located in Wuxi City, Jiangsu Province.
2. What can we provide?
We can provide solar panel, solar inverter, solar energy system.
3. Why choose us?
A. Higher power generation
B. Competitive price
C. High quality standard
D. Customized service
4. What services can we provide?
Accepted Delivery Terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU；
Accepted Payment Currency:USD, EUR, CNY;
Accepted Payment Type: T/T, L/C, PayPal, Western Union, Cash.
